Toky TEP Series

Toky TEP Series Professional Programmable Temperature Controller. Designed for complex thermal profiles with fuzzy intelligent PID and programmable curve capabilities. UL certification available.

Key Features:
• Programmable Curves: Supports up to 16-segment ramp & soak profiles with customizable duration.
• High Precision: 0.3% measurement accuracy with TC/RTD inputs.
• Intelligent PID: Fuzzy PID auto-tuning for fast response and high stability.
• Advanced Control Operations: Manual output, pause, stop, repeat, and PV start modes.

Back

Technical Specifications

Accuracy	0.3% Class Measurement Accuracy
Measurement Input	TC, RTD, mV, Rt (Standard), mA, V (Customizable)
Control Algorithm	Intelligent Fuzzy PID Auto-Tuning
Program Capabilities	Supports 16 segments of ramp & soak temperature curves
Control Output	Relay, SSR, SCR, DC 4-20mA Regulating/Transmission
Communication	RS485 with HMI & PLC compatibility
Alarm Output	Up to 2-way Relay Alarm Outputs
Options & Certifications	UL Certification (Optional)

Product Information

This temperature controller from Toky is designed to meet rigorous industrial standards, providing precise, real-time temperature tracking and automated adjustments to maintain optimal operational conditions.

For more detailed wiring diagrams, panel cutout dimensions, and Modbus registers, please download the product manual from our Download section or contact our engineering team.
