Toky DP4H/DP3 Series

Toky DP4H Series adalah instrumen pengukur tegangan dan arus digital 4.5 digit yang dirancang khusus untuk pengukuran sinyal kecil dengan resistansi input tinggi. Memberikan akurasi dan stabilitas luar biasa untuk berbagai aplikasi industri.

Key Features:
• High Resolution: 4.5 digit display for precise measurement monitoring.
• Low Signal Measurement: Designed specifically for micro-signal measurement with high input resistance.
• Dual Alarm: Two sets of dial switches to set upper and lower alarm limits intuitively.
• Analog Output: Optional isolated 4-20mA transmission output.
• Multi-function Display: Supports True RMS, Average, Hold, Max, and Min display modes.
• Communication: Optional RS485 communication (Modbus-RTU).

Back

Technical Specifications

Display	4.5 Digits LED
Accuracy	±0.3% F.S ± 2 Digits
Input Resistance	High Input Resistance (>10MΩ for Voltmeter)
Alarm Output	Two sets of relay alarm outputs (Upper/Lower)
Analog Output	Optional 4-20mA Transmission Output
Communication	Optional RS485 (Modbus RTU)
Refresh Rate	Adjustable 1 time/sec to 9 times/sec
Power Supply	AC/DC 85-265V

Product Information

Toky DP4H series is ideal for automatic detection lines in electronics, machinery, and other industries, especially for industries requiring high input impedance such as lithium battery testing.

For more detailed wiring diagrams and panel cutout dimensions, please download the product manual from our Download section or contact our engineering team.
