Toky CI Series

Toky CI Series Intelligent Length/Batch Counter Meter. Memiliki fungsi penghitungan (counting), pengukuran panjang (length measuring), dan batch counting. Dilengkapi dengan kecepatan respon pulsa tinggi hingga 10Kcps.

Key Features:
• High Speed: Response speed up to 10Kcps.
• Multi-function: Counting, Length, and Batch functions.
• Input Logic: PNP/NPN software switchable.
• Communication: Optional RS485 communication.
• Protection: Excellent anti-interference performance.

Back
Technical Specifications
Power Supply AC/DC 100-240V (Standard) or DC 12-24V
Counting Speed Up to 10Kcps
Input Signal Voltage Input (PNP) or Non-Voltage Input (NPN)
Output Channel 2 Groups of Counting Output + 1 Group Batch Output
Communication RS485 Modbus-RTU (Optional)
External Reset Available with adjustable pulse width
Working Env 0~50°C, 35~85% RH (No condensation)
Product Information

Toky CI Series is widely used in packaging, food, textile, and automotive industries for precise piece counting and material length measurement. With its 10Kcps high-speed response, it ensures no pulse is lost even in high-speed production lines.
